Individual-PC Asus A8N32-SLI Deluxe

General

• Chipset Type
  NVIDIA nForce4 SLI X16
• Compatible Processors
  Athlon 64, Athlon 64 FX, Athlon 64 X2
• Processor Socket
  Socket 939
• Max Bus Speed
  1000 MHz
• Max Processors Qty
  1
• Manufacturer
  Asus

Processor

• Max Supported Qty
  1
• Installed Qty
  1

Expansion / Connectivity

• Expansion Slots
  1 x CPU
  4 x DIMM 184-pin
  2 x PCI Express x16 (SLI: x16)
  1 x PCIe x4
  3 x PCI
• Storage Interfaces
  SATA-300 -connectors: 4 - RAID 0 / RAID 1 / RAID 0+1 / RAID 5 / JBOD
  ATA-133 -connectors: 2 x 40pin IDC
  Silicon Image SiI3132: SATA-300 -connectors: 1 x 7pin Serial ATA, 1 x 7pin external SATA - 1 devices - RAID 0 / RAID 1
• Internal Interfaces
  1 x floppy
• Power Connectors
  4-pin ATX12V connector, 24-pin main power connector

Networking

• Data Link Protocol
  Ethernet, Fast Ethernet, Gigabit Ethernet
• Network
  2 x Gigabit Ethernet

Interface Provided

• Qty
  1, 2
• Type
  FireWire, LAN (Gigabit Ethernet), audio line-out (rear), audio line-out (side surround), microphone, parallel, PS/2 keyboard, PS/2 mouse, SPDIF out, TOSLINK, USB 2.0, audio line-in, audio line-out, audio line-out (center/subwoofer)
• Connector Type
  mini-jack

Audio

• Audio Codec
  Realtek ALC850

RAM

• Max Supported Size
  4 GB
• Features
  dual channel memory architecture

Audio Output

• Sound Output Mode
  7.1 channel surround
• Type
  sound card
• Audio Codec
  Realtek ALC850
• Audio
  8-channel

LAN

• Network Interfaces
  2 x Gigabit Ethernet

Supported RAM

• Bus Clock
  400 MHz, 333 MHz, 266 MHz
• Features
  Dual channel memory architecture
• Registered or Buffered
  Unbuffered
• Speed
  PC3200, PC2700, PC2100
• Technology
  DDR
• Max Size
  4 GB
• Supported RAM Integrity Check
  Non-ECC

Header

• Brand
  ASUS
• Product Line
  ASUS
• Model
  A8N32-SLI Deluxe
• Edition
  AiLife Series Gaming Edition
• Packaged Quantity
  1
• Compatibility
  PC

Mainboard

• Form Factor
  ATX
• Processor Socket
  Socket 939
• Compatible Processors
  Athlon 64, Athlon 64 FX, Athlon 64 X2
• Data Bus Speed
  1000 MHz
• Chipset Type
  NVIDIA nForce4 SLI X16
• Supported RAM Technology
  DDR SDRAM
• Supported RAM Speed
  266 MHz, 333 MHz, 400 MHz
• Supported RAM Standard
  PC2100, PC2700, PC3200
• Supported RAM Integrity Check
  non-ECC
• Supported RAM (Registered or Buffered)
  unbuffered
• Power Connectors
  24-pin main power connector, 4-pin ATX12V connector

Mainboard Features

• BIOS Type
  AMI
• BIOS Features
  ASUS EZ Flash, ASUS MyLogo2, DMI 2.0 support, Multilingual BIOS, SMBIOS 2.3 support, WfM 2.0 support
• Sleep / Wake Up
  wake on LAN (WOL), wake on ring (WOR)
• Manual Settings
  CPU frequency, PCI Express x16 slot frequency, memory bus frequency, memory voltage
• Hardware Features
  AMD Cool 'n' Quiet Technology, ASUS Q-Fan 2, C.P.R. (CPU Parameter Recall), CrashFree BIOS 2, NVIDIA Firewall, Stack Cool 2, heat pipe chipset cooling

Interfaces

• Storage
  ATA-133, Serial ATA-300 (RAID)
• FireWire

Dimensions & Weight

• Width
  12 in
• Depth
  9.6 in

Storage Interfaces

• Chip
  Silicon Image SiI3132
• Interface
  ATA-133, Serial ATA-300
• Connector(s)
  1 x 7pin Serial ATA, 1 x 7pin external SATA, 2 x 40pin IDC, 4
• Supported Devices Qty
  1
• RAID (Level)
  RAID 0 / RAID 1

Features

• Manual Settings
  CPU frequency, memory voltage, memory bus frequency, PCI Express x16 slot frequency
• BIOS Type
  AMI
• Hardware Features
  C.P.R. (CPU Parameter Recall), CrashFree BIOS 2, AMD Cool 'n' Quiet Technology, ASUS Q-Fan 2, NVIDIA Firewall, Stack Cool 2, heat pipe chipset cooling
• BIOS Features
  DMI 2.0 support, WfM 2.0 support, Multilingual BIOS, ASUS MyLogo2, SMBIOS 2.3 support, ASUS EZ Flash
• Sleep / Wake Up
  Wake on LAN (WOL), wake on ring (WOR)
